Standard Production Strings
Used where corrosive production duty needs a practical tubing series with moderate pressure class and field handling advantages.
Products / Well
Composite Well Tubing and Casing
Corrosion-resistant composite well tubing and casing for production environments where pressure class, collapse resistance, handling efficiency, and long-term reliability all matter.
Product Overview
Well tubing and casing projects are usually driven by corrosive service, pressure class, collapse resistance, installation practicality, and lifecycle reliability in aggressive field environments where metallic options can raise weight and corrosion concerns.
Composite well products help project teams review series class, service fluid, dimensions, and connection planning together instead of treating the pipe body and well accessories as separate decisions.
Series Comparison
Current well tubing series summary for project screening.
This table helps buyers compare the main HW series before sending the well-service RFQ. The values below reflect the current source summary already used in the product cards.
| Product Route | Tubing Size | Burst Pressure | Commercial Position | Typical Fit |
|---|---|---|---|---|
| HW-1500 | 1 1/2 to 4 1/2 in. | Around 4000-4200 psig | Base production-duty tubing route | Standard corrosive production strings where lighter handling matters |
| HW-2000 | 1 1/2 to 4 1/2 in. | About 5000-5400 psig | Intermediate-duty tubing route | Projects needing stronger tensile and collapse values beyond the basic production class |
| HW-2500 | 1 1/2 to 4 1/2 in. | About 6800-7500 psig | Heavy-duty tubing route | Well strings that push further on burst and collapse envelope |
| HW-3000 | 1 1/2 to 2 7/8 in. | About 8000-8500 psig | Highest current source-table class | Projects that need the strongest current pressure route together with accessory and connection review |
Selection Paths
How to choose the right well product route.
Intermediate and Heavy-Duty Wells
Useful where higher burst, tensile, and collapse requirements push the well string toward stronger HW series routes.
Connections and Field Handling
Projects that depend on field handling efficiency, lighter strings, and clearer connection planning should define accessories early.
Our Product Range
Available product families and package items.
HW-1500
HW-1500 Well Tubing
Acid-anhydride tubing series for 1 1/2 to 4 1/2 inch well service with burst pressure around 4000 to 4200 psig, suited to standard corrosive production duty.
HW-2000
HW-2000 Well Tubing
Intermediate well tubing route for 1 1/2 to 4 1/2 inch service where higher tensile and collapse values are required beyond the basic production class.
HW-2500
HW-2500 Well Tubing
Heavy-duty tubing series for stronger burst and collapse envelopes, with 1 1/2 to 4 1/2 inch options and pressure classes around 6800 to 7500 psig.
HW-3000
HW-3000 Well Tubing and Connections
High-class tubing route for well service that needs the strongest burst and collapse performance in the current source table, together with connection and accessory review.
Built Around Actual Well Service Conditions
Well tubing and casing discussions should follow the real field environment, including service fluid, pressure class, size range, collapse requirements, connection logic, and handling conditions.
✓HW series selection
✓Burst and collapse review
✓Tubing size selection
✓Connection planning
✓Corrosion-duty review
✓Accessory clarification
Need a well tubing or casing review?
Share the service environment, requested size range, target pressure class, connection needs, and project location so Hovoy can align the right HW series to the field duty.
